DESCRIPTION

Basic Info

Model NO.	DCS-2B-1
Filling Principle	Auger Filling
Packaging Container Lifting Structure	Automatic
Structure	Semi Automatic
Packaging	Bottle
Packaging Material	Plastic
Semi Automatic Filling Machine	1-5000g
Transport Package	Plywood Wooden Carton
Specification	CE
Trademark	DAHEPACK
Origin	China
HS Code	842240000
Production Capacity	10units/Month

Product Description

Filling Machine, Packing Machine, Packaging Machine.

Introductions:

1# This is a automatic auger type bottles/cans metering filling Machine ,designed for filling and metering various dry powder into different rigid containers: Bottles, Cans and Jars.

2# The machine provides powder metering and filling function .

3# Bottles and cans are introduced by conveyor belt combined with gating System.

4#There is a photo eye sensor for bottle detection so to achieve a goal of bottle-fill and no-bottle no-fill.

5# Automatic Bottles/Cans positioning-filling-releasing, optional : elevation and vibration.

6# Featured with compact design, stable performance , easy to operate and good cost performance.

Speifications:

Model	DH-Q1-D100	DH-Q1-D160
Control System	PLC and Full color HMI
Hopper Volume	25L	50L
Filling Weight Range	1-500g(With different size dosing auger tools)	10-5000g(With different size dosing auger tools)
Filling Accuracy	<100g <+/-2% 100-500g <+/-1% >500g <+/-0.5%
Filling Rate	10-40Units/Min(Depends on fill weight, container size and product density)
Contact Parts	Fully Stainless Steel Construction and SUS304 for product contact parts
Power Supply	3P 208-415V 50/60HZ
Total Power	1.2KW	1.6KW
Total Weight	170KGS	300KGS
Air Consumption	4-6Bars
Overall Size	1500*760*1850MM	2000*970*2030MM
Optional: Unscrambling Table, Collecting Table,Screw Conveyor, Capping Machine, Induction Sealer, Labelling Machine etc.
