DESCRIPTION

Basic Info

Model NO.	RotaFill-Series
After-sales Service	Online Guidance
Warranty	5 Years
Usage	Produce Packing Belt, Auto Liquid Bottling Filling Line
Packaging Material	Glass/Plastic
Packaging	Bottles
Driven Type	Electric
Type	Beer/Wine/Water/Production Line
Function	Bottle Filling.Washing.Capping Machine
Packaging Technology	Leak Proof Packing
Application	Drinks, Dairy Products, Oil, Liquid Bottle
Soft and Hardness	Bottle Packing Line
Circulation Function	In the Packaging
Frequency of Use	One Packaging
Mode of Operation	Packaging of Export Products
Item	Bottle Filling and Washing Equipment
Capacity	12, 000-24, 000bottles Per Hour
Filling Volume	5-30ml
Using Field	Oral Liquid, Syrup, Water, etc.
Production Line Consist	Ultrasonic Washing Machine, Infrared Drying Tunnel
Transport Package	Export Standard Wooden Case
Specification	SGS, CE
Trademark	LTPM
Origin	China
Production Capacity	25-100 Sets/Month

Product Description

Attention: 1 --- All prices and parameters shown above are automatically generated by the system, if you want to know the exact information, please click "Contact Supplier" to send mail to us. 2 --- Because of the time difference, we suggest that you can choose to send us an inquiry instead of online chat. 3 --- When sending us an enquiry or message, please tell us your Email or WhatsApp/Wechat/Skype .etc, then our sales manager can contact you quickly.

Product Description
This unit is a combined multi-functional unit that integrates washing, filling and capping. It is one of the most ideal small and medium-sized beverage machinery equipment in China. The whole machine adopts advanced man-machine interface operation, PLC control, variable frequency stepless speed regulation and other automatic control technology. It has automatic shutdown at low temperature, automatic control of feeding and returning, with no bottle and no cover, bottle waiting, bottle bottle stop, The cover is automatically closed when the cover is not closed. Four Part Of Machine 1.Washing Part,
2.Filling part,
3.Capping part
4.Star wheel part. The height of the bottle washing machine ,filling machine and cap screwing machine has been adjusted before they are carried out of the factory. They can suitable for different sizes bottles in the designing scale. Empty bottles are conveyed to the bottle washing machine with air conveying system through bottle entering spider .The bottle will turn up 180o ---washing bottle ----dropping water -bottle turn up 180o ,the bottle mouth is upward .The bottle is carried to the filling machine through transferring spider and settle down at the part of bayonet of bottle mouth of the filling machine. .And it switches with the filling valve. If there is a bottle ,the filling begins .If there is not a bottle , the valve closes. After the filling ends, the filled bottle is carried to the cap screwing machine through the transferring spider of the work table of the cap screwing machine .The capped bottle is conveyed to the next process (equipment) with the bottle exiting spider through the exhaust bottle belt.

Technical Parameters

Capacity 2500BPH (500ml) Bottle Height 150~310mm Bottle Diameter 50~96mm(diameter) Bottle Type PET bottle Cap HDPE Cap Washing Head 8 Washing Capacity 1000kgs/hour Washing Pressure 0.2-0.4Mpa Filling Heads 8 Capping Heads 3 Rated Voltage 220V/380V,50/60HZ, 3 phase Main Motor Power 1.5kw Total Motor Power 3kw Overall dimension 2000*1800*2100mm Weight 1800Kg

Machine details

Final Product
Company Introduction
Our CompanyZhejiang LeadTop Pharmaceutical Machinery Co.,ltd well known as LTPM China. Since year 1996, we are start manufacturing Oral Solid Dosage Pharmaceutical Machinery includes Mixing Machine, Drying Equipment, granulation line, IBC Bin and Bin Washing Machine. As year passed, LTPM China absorb advanced domestic and abroad technology, we export machinery to more than 30 countries all over the world.
LTPM China is considered one of the major Pharmaceutical Machinery Supplier and exporter in China mainland. Professional, Enthusiasm, Service and Team Work has been always our value to create for our Staff and customers. As year 2012 we position our value as "A Pharma Machinery Division, For A Better Life", creating a Win-Win Platform for our clients and staff for a better life is our vision.
Our Machinery Manufacturing WorkshopImported CNC Machining Centre makes all parts process accurate. Own R&D team with more than 20 years engineering expereince, can customize the equipment and packaging line to your satisfaction.Professional Business TeamWarm, professional business team, careful response to your inquiry, timely response rate of more than 93%, higher than the average level of the industry.Our CertificatesISO, CE, S
Packing & ShippingAll machine delivery with anti rust spray, film wrapping and Sea shipping affordable wooden box.

FAQQ: What price terms you offer?
A: We can offer FOB, FCA, CFR, CIF, EXW and other price terms based on your request
Q: What payment terms you take?
A: TT, LC, other terms are also workable
Q: Will you help with installation and stuff training?
A: Yes, we can send our engineers to your place to guide the installation and train your workers if you need, but the buyer shouldbear our technician's round tickets, accomodation, food and subsidiary USD100/day
Q: How can I visit your factory?
A: Our factory is located in Ruian city Zhejiang Province. Just let us know your scheduel in advance and we will arrangeeverything for you!Any other doubts about our machine, please feel easy to contact with us.
